EURACRYL PL-R
VHM-Radienfräser in Standard-Qualität zum Abrunden der oberen Materialkante. Für die Bearbeitung von Acrylglas (PMMA), Polycarbonat und anderen Kunststoffen sowie Leichtmetallen. Rechtsdrehend, mit gerader Schneide.
| Best.-Nr. | 505 050, 505 051, 505 052, 505 100, 505 101, 505 102, 505 150, 505 151, 505 152, 505 200, 505 201, 505 202, 505 250, 505 251, 505 252, 505 300, 505 301, 505 302, 505 350, 505 351, 505 400, 505 401, 505 402, 505 451, 505 500, 505 501, 505 502, 505 600, 505 601, 505 602 |
|---|---|
| R | |
| D1 | 1,5, 10,0, 11,0, 12,0, 13,0, 14,0, 16,0, 3,0, 4,6, 5,5, 6,0, 6,5, 7,5, 8,0 |
| D3 | |
| L3 | |
| L1 | |
| D2 | |
| Z | |
| VPE |
| Best.-Nr. | R | D1 | D3 | L3 | L1 | D2 | Z | VPE | Preis | Menge |
|---|---|---|---|---|---|---|---|---|---|---|
| 505 050 | 0,5 | 1,5 | 1 | 2,5 | 50 | 3 | 2 | 1 | 41,60€ | |
| 505 052 | 0,5 | 3,0 | 2 | -- | 40 | 3 | 3 | 1 | 35,00€ | |
| 505 051 | 0,5 | 6,0 | 5 | -- | 50 | 6 | 2 | 1 | 41,60€ | |
| 505 100 | 1,0 | 3,0 | 1 | 4,0 | 50 | 3 | 2 | 1 | 41,60€ | |
| 505 102 | 1,0 | 6,0 | 4 | -- | 50 | 6 | 3 | 1 | 36,50€ | |
| 505 101 | 1,0 | 6,0 | 4 | -- | 50 | 6 | 2 | 1 | 41,60€ | |
| 505 150 | 1,5 | 4,6 | 2 | 6,0 | 50 | 5 | 2 | 1 | 52,50€ | |
| 505 152 | 1,5 | 6,0 | 3 | -- | 50 | 6 | 3 | 1 | 36,00€ | |
| 505 151 | 1,5 | 6,0 | 3 | -- | 50 | 6 | 2 | 1 | 43,20€ | |
| 505 200 | 2,0 | 5,5 | 2 | 8,0 | 50 | 6 | 2 | 1 | 52,40€ | |
| 505 202 | 2,0 | 6,0 | 2 | -- | 50 | 6 | 3 | 1 | 36,50€ | |
| 505 201 | 2,0 | 6,0 | 2 | -- | 50 | 6 | 2 | 1 | 43,20€ | |
| 505 250 | 2,5 | 6,5 | 2 | 10,0 | 50 | 8 | 2 | 1 | 67,50€ | |
| 505 252 | 2,5 | 8,0 | 3 | -- | 50 | 8 | 3 | 1 | 53,00€ | |
| 505 251 | 2,5 | 8,0 | 3 | -- | 50 | 6 | 4 | 1 | 68,50€ | |
| 505 300 | 3,0 | 7,5 | 2 | 10,0 | 50 | 8 | 2 | 1 | 67,50€ | |
| 505 302 | 3,0 | 8,0 | 2 | -- | 50 | 6 | 3 | 1 | 58,00€ | |
| 505 301 | 3,0 | 10,0 | 4 | -- | 50 | 6 | 4 | 1 | 82,50€ | |
| 505 350 | 3,5 | 10,0 | 3 | -- | 50 | 6 | 3 | 1 | 68,50€ | |
| 505 351 | 3,5 | 11,0 | 4 | -- | 50 | 6 | 4 | 1 | 96,50€ | |
| 505 400 | 4,0 | 10,0 | 2 | -- | 55 | 10 | 2 | 1 | 105,00€ | |
| 505 402 | 4,0 | 10,0 | 2 | -- | 50 | 6 | 3 | 1 | 75,00€ | |
| 505 401 | 4,0 | 12,0 | 4 | -- | 50 | 6 | 4 | 1 | 104,00€ | |
| 505 451 | 4,5 | 12,0 | 3 | -- | 50 | 6 | 4 | 1 | 104,00€ | |
| 505 500 | 5,0 | 12,0 | 2 | -- | 63 | 12 | 2 | 1 | 115,00€ | |
| 505 502 | 5,0 | 12,0 | 2 | -- | 50 | 6 | 3 | 1 | 86,00€ | |
| 505 501 | 5,0 | 13,0 | 3 | -- | 50 | 6 | 4 | 1 | 116,00€ | |
| 505 600 | 6,0 | 14,0 | 2 | -- | 74 | 14 | 2 | 1 | 189,00€ | |
| 505 602 | 6,0 | 14,0 | 2 | -- | 50 | 6 | 3 | 1 | 102,00€ | |
| 505 601 | 6,0 | 16,0 | 4 | -- | 50 | 6 | 4 | 1 | 125,00€ | |
